Chapter 6 Replaceable Parts
E3631-60002 Top PCB Assembly
105
6
E3631-60002 Top PCB Assembly
Reference
Designator
Agilent Part
Number
Qty Description
Mfr
Code
Mfr Part Number
C1-C2 0160-6497 26 CAP-FXD 0.1uF+-10% 50V CER X7R 04222 12065C104KAT A
C3 0180-4116 2 CAP-FXD 22uF +-20% 20V TA 12340 T491D226M020AS
C4-C5 0160-6497 CAP-FXD 0.1uF+-10% 50V CER X7R 04222 12065C104KAT A
C6-C7 0160-6736 5 CAP-FXD 0.01uF +-10% 50V CER X7R 12340 C1206C103K5RAC
C8-C9 0160-6497 CAP-FXD 0.1uF+-10% 50V CER X7R 04222 12065C104KAT A
C10-C15 0160-5892 8 CAP-FXD 0.22uF +-10% 63V POLYE-MET 05524 MKT1817422065
C16 0160-6497 CAP-FXD 0.1uF+-10% 50V CER X7R 04222 12065C104KAT A
C18-C19 0160-5954 2 CAP-FXD 220pF +-10% 50V CER COG 04222 08051A221JAT A
C20-C25 0160-6497 CAP-FXD 0.1uF+-10% 50V CER X7R 04222 12065C104KAT A
C26 0180-3643 1 CAP-FXD 470uF +-20% 25V AL-ELCTLT S4217
SME25VB471M10X16LL
C27-C31 0160-6497 CAP-FXD 0.1uF+-10% 50V CER X7R 04222 12065C104KAT A
C32 0180-4116 CAP-FXD 22uF +-20% 20V TA 12340 T491D226M020AS
C33 0160-6736 CAP-FXD 0.01uF +-10% 50V CER X7R 12340 C1206C103K5RAC
C34-C36 0180-3657 6 CAP-FXD 1000uF +-20% 63V AL-ELCTLT S4217
KME63VB102M16X31LL
C37 0160-6497 CAP-FXD 0.1uF+-10% 50V CER X7R 04222 12065C104KAT A
C38-C39 0160-6104 4 CAP-FXD 2200pF +-5% 50V CER COG 12340 C1206C222J5GAC
C40 0160-6736 CAP-FXD 0.01uF +-10% 50V CER X7R 12340 C1206C103K5RAC
C41 0160-6225 4 CAP 0.33UF +-10% 250V POLYE-MET 06127 MKS4-.33/250/10
C44-C45 0180-2980 2 CAP-FXD 1000uF +-20% 50V AL-ELCTLT S4217
SME50VB102M16X25LL
C46-C47 0180-3751 2 CAP-FXD 1uF +-20% 35V TA 12340 T491B105M035AS
C48 0160-6225 CAP 0.33UF +-10% 250V POLYE-MET 06127 MKS4-.33/250/10
C49-C50 0160-6940 2 CAP-FXD 0.33uF +-20% 50V CER Z5U 04222 12105E334MAT A
C51-C52 0160-6104 CAP-FXD 2200pF +-5% 50V CER COG 12340 C1206C222J5GAC
C53 0160-6736 CAP-FXD 0.01uF +-10% 50V CER X7R 12340 C1206C103K5RAC
C54-C56 0180-3657 CAP-FXD 1000uF +-20% 63V AL-ELCTLT S4217
KME63VB102M16X31LL
C57 0160-6497 CAP-FXD 0.1uF+-10% 50V CER X7R 04222 12065C104KAT A
C58-C59 0160-6225 CAP 0.33UF +-10% 250V POLYE-MET 06127 MKS4-.33/250/10
C60-C65 0160-6497 CAP-FXD 0.1uF+-10% 50V CER X7R 04222 12065C104KAT A
C66 0160-5967 2 CAP-FXD 100pF +-5% 50V CER COG 12340 C0805C101J5GAC
C67-C68 0160-4535 CAP-FXD 1uF +-10% 50V CER X7R 12340 C330C105K5R5CA
C69 0160-5967 CAP-FXD 100pF +-5% 50V CER COG 12340 C0805C101J5GAC
C70-C71 0160-5947 2 CAP-FXD 1000pF +-10% 50V CER X7R 04222 08055C102KATA
C72 0160-5892 CAP-FXD 0.22uF +-10% 63V POLYE-MET 05524 MKT1817422065
C73-C74 0160-7221 2 CAP-FXD 0.1uF +-10% 50V CER X7R 02010 SA115C104KAAH
C75-C78 0160-4832 4 CAP-FXD 0.01uF +-10% 100V CER X7R 02010 SA101C103KAAH
To Next Page
