Chapter 6 Replaceable Parts
E3631-60002 Top PCB Assembly
106
Reference
Designator
Agilent Part
Number
Qty Description Mfr
Code
Mfr Part Number
CR1-CR3 1906-0291 10 DIODE-DUAL 70V 100mA TO-236 AA 28480 1906-0291
CR4-CR6 1901-1149 13 DIODE-PWR RECT 400V 1A 50NS DO-41 71744 UF4004
CR7 1906-0351 2 DIODE-FW BRDG 200V 2A 71744 2KBP02M
CR8-CR10 1906-0291 DIODE-DUAL 70V 100mA TO-236 AA 28480 1906-0291
CR11-CR12 1901-1227 11 DIODE-SWICHING 75V 200mA 6nS TO-236 27014 BAS16
CR13-CR14 1901-1165 2 DIODE-SHOTTKY 60V 1A DO-41 71744 SB160
CR15-CR19 1901-1149 DIODE-PWR RECT 400V 1A 50NS DO-41 71744 UF4004
CR20 1906-0407 1 DIODE-FW BRDG 400V 1A 71744 DF04S
CR21 1901-1149 DIODE-PWR RECT 400V 1A 50NS DO-41 71744 UF4004
CR22-CR23 1906-0291 DIODE-DUAL 70V 100mA TO-236 AA 28480 1906-0291
CR24 1901-1227 DIODE-SWICHING 75V 200mA 6nS TO-236 27014 BAS16
CR25-CR26 1906-0291 DIODE-DUAL 70V 100mA TO-236 AA 28480 1906-0291
CR28 1901-1227 DIODE-SWICHING 75V 200mA 6nS TO-236 27014 BAS16
CR29 1906-0351 DIODE-FW BRDG 200V 2A 71744 2KBP02M
CR30-CR31 1901-1149 DIODE-PWR RECT 400V 1A 50NS DO-41 71744 UF4004
CR32-CR37 1901-1227 DIODE-SWICHING 75V 200mA 6nS TO-236 27014 BAS16
VR1-VR3 1902-1542 3 DIODE-ZNR 6.2V 5% TO-236(SOT-23) 04713 BZX84C6V2
VR4 1902-0579 1 DIODE-ZNR 5.1V 5% PD=1W IR=10uA 04713 1N4733ARL
VR5 1902-0651 1 DIODE-ZNR 9.1V 5% PD=1W IR=10uA 04713 1N4739A
VR6 1902-3002 1 DIODE-ZNR 2.37V 5% DO-7 PD=.4W TC=.074% 04713 SZ30016-2
J1 1252-6880 1 CONN-POST-TYPE HDR 8P 27264 22-03-5085
J2 1251-5066 1 CONN-POST TYPE.098-PIN-SPCG-MTG-EN 27264 5045-02A
J3-J4 1252-7162 CONNECTOR-TIN-PLATED 12-PIN 27264 1252-7162
J5 1252-6914 1 CONN-POST TYPE.156-PIN-SPCG-MTG-EN 27264 09-65-2068
J6 1251-8363 2 CONN-POST TYPE.156-PIN-SPCG-MTG-EN 27264 09-65-2038
J7 1252-7453 CONN-POST-TYPE PST 27264 09-65-2085
J8 1251-8363 CONN-POST TYPE.156-PIN-SPCG-MTG-EN 27264 09-65-2038
Q1 1854-1233 1 TRANSISTOR NPN SI TO-218AC PD=125W 04713 TIP35C
Q2 1853-0590 1 TRANSISTOR 2N4036 SI TO-5 PD=1W 04713 2N4036
Q3 1854-1320 2 THYRISTOR-TRIAC TO-220AB VRRM=600 50080 BTA06-600B
Q4 1854-1053 3 TRANSISTOR NPN SI SOT-23(TO-236AB) 04713 MMBT2222ALT1
Q5 1853-0525 1 TRANSISTOR PNP SI TO-236AA PD=200mW 04713 MMBT2907A
Q6 1854-1053 TRANSISTOR NPN SI SOT-23(TO-236AB) 04713 MMBT2222ALT1
Q7 1853-0709 1 TRANSISTOR PNP SI TO-218AC PD=125W 04713 TIP36C
Q8 1854-0039 1 TRANSISTOR NPN 2N3053A SI TO-39 PD=1W 04713 2N3053S
Q9 1854-1053 TRANSISTOR NPN SI SOT-23(TO-236AB) 04713 MMBT2222ALT1
Q10 1854-1320 THYRISTOR-TRIAC TO-220AB VRRM=600 50080 BTA06-600B
E1-E5 9170-1431 5 CORE-SHIELDING BEAD 06352 HF50ACB-453215
