Agilent Technologies E3631A Service Manual

Chapter 6 Replaceable Parts
E3631-60002 Top PCB Assembly
107
6
Reference
Designator
Agilent Part
Number
Qty Description Mfr
Code
Mfr Part Number
F1-F2 0699-2715 2 RESISTOR-FUSE 1 OHM +-5% 0.5W @70 28480 0699-2715
R1 0699-1405 4 RESISTOR 38.3K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R2-R3 0699-1385 2 RESISTOR 5.11K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R4-R5 0699-2837 2 RESISTOR 30K +-0.1% .125W TF TC=0+-25 11502 W1206R033001BT
R6-R8 0699-2489 3 RESISTOR 10K +-0.1% .125W TF TC=0+-25 11502 W1206R031002BT
R9 0699-2491 1 RESISTOR 20K +-0.1% .125W TF TC=0+-25 11502 W1206R032002BT
R10 0699-1318 11 RESISTOR 1K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R11-R12 0699-1389 2 RESISTOR 8.25K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R13 0699-1391 10 RESISTOR 10K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R14 0699-1348 1 RESISTOR 14.7 +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R15 0699-2222 1 RESISTOR 100K +-.5% .125W TKF TC=0+-25 11502 W1206R031003D
R16 0699-1405 RESISTOR 38.3K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R17 0699-4278 1 RESISTOR 7.15K +-0.1% .125W TF TC=0+-25 2M627 MCR18FX
R18 0699-2837 1 RESISTOR 30K +-0.1% .125W TF TC=0+-25 2M627 MCR18FX
R19 0699-2506 1 RESISTOR 7.15K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R20 0699-1330 2 RESISTOR 100K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R21 0699-1380 7 RESISTOR 3.16K +-1% .125 TKF TC=0+-100 2M627 MCR18FX
R22-R27 0699-1423 16 RESISTOR 215 +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R28 0699-1344 1 RESISTOR 10 +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R29-R33 0699-1318 RESISTOR 1K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R34 0699-1330 RESISTOR 100K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R36-R39 0699-1423 RESISTOR 215 +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R40 0699-1386 3 RESISTOR 5.62K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R41-R42 0699-1423 RESISTOR 215 +-1%.125W TKF TC=0+-100 2M627 MCR18FX
R43-R45 0699-1391 RESISTOR 10K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R46 0811-2188 4 RESISTOR 5K +-5% 3W PWI TC=0+-20 91637 RS-2 5K05%
R47 0699-1357 2 RESISTOR 34.8 +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R48 0699-1386 RESISTOR 5.62K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R49 0699-1391 RESISTOR 10K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R50 0699-1405 RESISTOR 38.3K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R51 0699-1318 RESISTOR 1K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R53 0699-1396 2 RESISTOR 17.8K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R54 0699-3590 2 RESISTOR 22.1K +-0.1% .125W TF TC=0+-25 2M627 MCR18FX
R55 0699-1332 2 RESISTOR 196K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R56 0699-2822 2 RESISTOR 200K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R57 0699-1423 RESISTOR 215 +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R58 0699-1318 RESISTOR 1K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R59 0699-1391 RESISTOR 10K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
