Agilent Technologies E3631A Service Manual

Chapter 6 Replaceable Parts
E3631-60002 Top PCB Assembly
108
Reference
Designator
Agilent Part
Number
Qty Description Mfr
Code
Mfr Part Number
R60 0699-1456 2 RESISTOR 562K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R61 0699-1381 1 RESISTOR 3.48K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R62 0757-0813 2 RESISTOR 475 +-1% .5W TF TC=0+-100 91637 CMF-654750FT-1
R63 0811-2188 RESISTOR 5K +-5% 3W PWI TC=0+-20 91637 RS-2 5K05%
R64 0699-2721 2 RESISTOR 3.16K +-0.1% .125W TF TC=0+-25 2M627 MCR18FX
R65 0699-3151 2 RESISTOR 261K +-0.1% .125W TF TC=0+-250 2M627 MCR18FX
R66-R67 0811-3909 2 RESISTOR .2 +-1% 10W PWI TC=0+-90 28480 0811-3909
R68 0699-3151 RESISTOR 261K +-0.1% .125W TF TC=0+-250 2M627 MCR18FX
R69 0699-2721 RESISTOR 3.16K +-0.1% .125W TF TC=0+-25 2M627 MCR18FX
R72 0811-2188 RESISTOR 5K +-5% 3W PWI TC=0+-20 91637 RS-2 5K05%
R73 0764-0033 1 RESISTOR 33 +-%5% 2W MO TC=0+-200 91637 FP69 33R0 5%
R74 0699-1394 11 RESISTOR 14.7K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R75 0699-1391 RESISTOR 10K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R76 0699-1394 RESISTOR 14.7K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R77-R78 0699-1415 2 RESISTOR 100 +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R79 0699-1425 4 RESISTOR 261 +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R80 0699-1394 RESISTOR 14.7K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R81 0699-1380 RESISTOR 3.16K +-1% .125 TKF TC=0+-100 2M627 MCR18FX
R82 0699-1425 RESISTOR 261 +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R83 0699-1380 RESISTOR 3.16K +-1% .125 TKF TC=0+-100 2M627 MCR18FX
R84 0699-1425 RESISTOR 261 +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R85 0699-1405 RESISTOR 38.3K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R86 0699-1394 RESISTOR 14.7K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R87 0699-1423 RESISTOR 215 +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R88 0699-1318 RESISTOR 1K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R89 0699-3590 RESISTOR 22.1K +-0.1% .125W TF TC=0+-25 2M627 MCR18FX
R90 0699-2822 RESISTOR 200K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R91 0699-1391 RESISTOR 10K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R92 0699-1380 RESISTOR 3.16K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R93 0699-1318 RESISTOR 1K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R94 0699-1403 3 RESISTOR 31.6K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R95 0699-1377 1 RESISTOR 2.37K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R96 0699-1332 RESISTOR 196K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R97 0699-1396 RESISTOR 17.8K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R98 0811-2188 RESISTOR 5K +-5% 3W PWI TC=0+-20 91637 RS-2 5K05%
R99 0699-1386 RESISTOR 5.62K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R100 0699-1456 RESISTOR 562K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R101 0699-1394 RESISTOR 14.7K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
