Chapter 6 Replaceable Parts
E3631-60002 Top PCB Assembly
109
6
Reference
Designator
Agilent Part
Number
Qty Description Mfr
Code
Mfr Part Number
R103 0699-1357 RESISTOR 34.8 +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R106-R107 0699-1391 RESISTOR 10K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R108 0757-0813 RESISTOR 475 +-1% .5W TF TC=0+-100 91637 CMF-654750FT-1
R109 0699-1403 RESISTOR 31.6K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R110 0699-1394 RESISTOR 14.7K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R111 0699-1403 RESISTOR 31.6K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R112 0699-1394 RESISTOR 14.7K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R113 0699-3431 4 RESISTOR 4.99K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R114 0699-1394 RESISTOR 14.7K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R115 0699-3431 RESISTOR 4.99K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R116 0699-1394 RESISTOR 14.7K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R117 0699-3431 RESISTOR 4.99K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R118-R119 0699-1394 RESISTOR 14.7K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R120 0699-3431 RESISTOR 4.99K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R122 0699-1425 RESISTOR 261 +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R123-R124 0699-1423 RESISTOR 215 +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R125 0699-1423 RESISTOR 215 +-1% .125W TKF TC=0+-100 05524 CRCW12062150F
R126-R129 0699-2837 4 RESISTOR 30K +-0.1% .125W TF TC=0+-25 05524 PTN1206E3002BB
RT1-RT8 0837-0261 8 V SUPPRESSOR 650V 4500A 34371 V275LA20A
U1 1826-4284 1 IC PWR MGT-V-REG-L-DDRPOUT 4.85/5.15V 01870 CS-8126-1THE5
U2 1826-1838 1 IC PWR MGT-V-REF-FXD 4.95/5.05V 8PIN 10858 LT1021DCS8-5
U3 1826-2420 2 IC OP AMP LP DUAL 8PIN PLSTC-SOIC 24355 AD706JR
U4 1821-0434 2 IC ANLG-MUXR/DEMUXR CMOS/HC 8-CHA 28480 1821-0434
U5 1820-4346 1 IC MUXR/DATA-SEL CMOS/HC 2-TO-1LINE 28480 1820-4346
U6 1826-1925 1 IC OP AMP LOW-NOISE SINGLE 8PIN 24355 OP-27GS
U7 1826-2420 IC OP AMP LP DUAL 8PIN PLSTC-SOIC 24355 AD706JR
U8 1826-1991 1 IC CP AMP HS SINGLE 8PIN PLSTC-SOIC 24355 AD711JR
U9-U10 1826-1622 3 IC OP AMP LOW-BIOS-H-IMPD QUAD 14PIN 01295 TL074D
U11 1820-5790 1 IC SHF-RGTR CMOS/HC SYNCHRO SERIAL 28480 1820-5790
U12 1826-2793 1 D/A 16-BIT 16-P-SOIC BICMOS 24355 AD1851R
U13 1821-0434 IC ANLG-MUXR/DEMUXR CMOS/HC 8-CHA 28480 1821-0434
U14 1818-5187 1 IC 2M-BIT OTP 150-NS CMOS 01295
TMS27PC020-150FML
U15 1818-4777 1 IC 256K-BIT SRAM 70-NS COMS S0482 CXK58257AM-70L
U16 1820-8907 1 IC-ASIC GT-ARY 600 GATES CMOS SCX6200 27014 SCX6206AK0
U17 1820-6721 1 IC-16-BIT MCU A/D I/O TIMER N80C196KB12
U18 1818-5236 1 IC 4K-BIT EEPROM 500-NS CMOS 27014 NM93C66M8
U19 1820-5478 1 IC FF CMOS/HCT D-TYPE POS-EDGE-TRIG 28480 1820-5478
U20 1826-0393 2 IC PWR MGT-V-REG-ADJ-POS 1.2/37V 3PINS 27014 LM317T
