Agilent Technologies E3631A Service Manual

Chapter 6 Replaceable Parts
E3631-60002 Top PCB Assembly
110
Reference
Designator
Agilent Part
Number
Qty Description Mfr
Code
Mfr Part Number
U21 1826-1862 1 IC OP AMP LOW-BIAS-H-IMPD DUAL 8 PIN 01295 TL072ACD
U22 1990-1659 2 OPTO-ISOLATOR LED-PTRIAC IF=50mA-max 12601 MCP3020Z
U23 1826-1572 2 IC COMPARATOR PRCN DUAL 8PIN PLSTC 01295 LM393D
U24 1826-0527 1 IC PWR MGT-V-REG-ADJ-NEG 1.2/37V 3PINS 27014 LM337T
U25 1826-0393 1 IC PWR MGT-V-REG-ADJ-POS 1.2/37V 3PINS 27014 LM317T
U26 1826-1622 IC OP AMP LOW-BIOS-H-IMPD QUAD 14PIN 01295 TL074D
U27 1826-0393 IC PWR MGT-V-REG-ADJ-POS 1.2/37V 3PINS 27014 LM317T
U28 1826-1572 IC COMPARATOR PRCN DUAL 8PIN PLSTC 01295 LM393D
U29 1990-1659 OPTO-ISOLATOR LED-PTRIAC IF=50mA-max 12601 MCP3020Z
U30 1826-1528 1 IC COMPARATOR LP QUAD 14PIN PLSTC-SOIC 27014 LM339M
Y1 0410-4009 1 RESONATOR-CERAMIC 12MHz 00830 PBRC-12.0BRN07
