Chapter 6 Replaceable Parts
E3631-60003 VFD Assembly
111
6
E3631-60003 VFD Assembly
Reference
Designator
Agilent Part
Number
Qty Description Mfr
Code
Mfr Part Number
C1-C3 0160-6497 14 CAP-FXD 0.1uF+-10%50V CER COG 04222 12065C104KAT2A
C4-C5 0180-3751 2 CAP-FXD 1uF+-20%35V TA 12340 T491B105M035AS
C6 0160-5945 3 CAP-FXD 0.01uF+-10%50V CERX7R 04222 08055C103KAT A
C7-C8 0160-6497 CAP-FXD 0.1uF+-10%50V CER COG 04222 12065C104KAT2A
C9 0160-5945 CAP-FXD 0.01uF+-10%50V CERX7R 04222 08055C103KAT A
C10-C15 0160-6497 CAP-FXD 0.1uF+-10%50V CER COG 04222 12065C104KAT2A
C16-C17 0160-5947 2 CAP-FXD 1000pF+-10% 50V CER COG 04222 08055C102KAT A
C18 0160-5945 CAP-FXD 0.01uF+-10%50V CERX7R 04222 08055C103KAT A
C19-C20 0160-6497 CAP-FXD 0.1uF+-10%50V CER COG 04222 12065C104KAT2A
C25 0160-6497 CAP-FXD 0.1uF+-10%50V CER COG 04222 12065C104KAT2A
CR1 1906-0291 1 DIODE-DUAL 70V 100mA TO-236 AA 28480 1906-0291
CR2 1902-1542 1 DIODE-ZNR 6.2V 5% TO-236(SOT-23) 04713 BZX84C6V2
Q1-Q2 1854-1053 2 TRANSISTOR NPN SI SOT-23(TO-236AB) 04713 MMBT2222ALT1
R1-R4 0699-1348 4 RESISTOR 14.7 +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R5 0699-1391 8 RESISTOR 10K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R6 0699-1400 2 RESISTOR 26.1K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R7-R9 0699-1391 RESISTOR 10K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R10 0699-1318 1 RESISTOR 1K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R11 0699-1391 RESISTOR 10K +-1% .125W TKF TC=0+-100 2M627 2M627
R12 0699-1378 1 RESISTOR 2.61K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R13-R15 0699-1391 RESISTOR 10K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R16-R19 0699-1423 4 RESISTOR 215 +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R20-R21 0699-1330 2 RESISTOR 100K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R22 0699-1400 RESISTOR 26.1K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
U1 1820-5330 1 IC-INTERFACE DRVR BIPOLAR DISPLAY 01295 SN75518FN
U2 1826-1402 1 IC PWR MGT-V-REG-FXD-POS 4.8/5.2V 8PINS 27014 LM78L05ACM
U3 1826-2264 1 IC PWR MGT-UND-V-SEN 8 PINS P-SOIC PKG 04713 MC34064D-5
U4 1820-5562 1 IC GATE CMOS/HC NOR QUAD 2-INP 28480 1820-5562
U5 1820-5478 1 IC FF CMOS/HCT D-TYPE POS-EDGE-TRIG 28480 1820-5478
U6 1820-6756 1 IC SHF-RGTR COMS/HC MULTI-MODE 27014 MM74HC299WM
U7 34401-88804 1 IC-8-BIT MCU W/4K EPROM;12MHZ 34649 N87C51
U8 1826-1528 1 IC COMPARATOR LP QUAD 14PIN PLST-SOIC 27014 LM339M
U9 E3631-60031 1 VFD 28480 E3631-60031
Y1 0410-4009 1 RESONATOR-CERAMIC 12MHz 00830 PBRC-12.0BRN07
J1 1252-7161 1 CONNECTOR-TIN-PLATED 12-P(RGHT-ANGLE) 28480 1252-7161
