Chapter 6 Replaceable Parts
E3631-60004 Bottom PCB Assembly
112
E3631-60004 Bottom PCB Assembly
Reference
Designator
Agilent Part
Number
Qty Description Mfr
Code
Mfr Part Number
SW1 3101-2985 1 SWITCH-PB DPST-NO ALTNG 4A 250VAC 28480 3101-2985
C1-C6 0160-6497 21 CAP-FXD 0.1uF+-10%50V CER X7R 04222 12065C104KAT A
C7 0180-4228 1 CAP-FXD 47uF +-20% 10V TA 12340 T491D476M010AS
C8 0180-3751 3 CAP-FXD 1uF +-20% 35V TA 12340 T491B105M035AS
C9 0160-6940 3 CAP-FXD 0.33uF +-20% 50V CER Z5U 04222 12105E334MAT A
C10-C14 0160-6497 CAP-FXD 0.1uF+-10%50V CER X7R 04222 12065C104KAT A
C15 0180-2980 3 CAP-FXD 1000uF +-20% 50V AL-ELCTLT S4217
SME50VB102M16X25LL
C16 0160-5959 4 CAP-FXD 33pF +-5% 50V CER COG 04222 08051A330JATA
C17 0160-6497 CAP-FXD 0.1uF+-10%50V CER X7R 04222 12065C104KAT A
C18 0160-5959 CAP-FXD 33pF +-5% 50V CER COG 04222 08051A330JATA
C19 0160-6497 CAP-FXD 0.1uF+-10%50V CER X7R 04222 12065C104KAT A
C20 0160-5957 4 CAP-FXD 47pF +-5% 50V CER COG 51406 GRM39COG470J50*
C21-C22 0160-6497 CAP-FXD 0.1uF+-10%50V CER X7R 04222 12065C104KAT A
C23-C24 0160-5957 CAP-FXD 47pF +-5% 50V CER COG 51406 GRM39COG470J50*
C25-C26 0160-6497 CAP-FXD 0.1uF+-10%50V CER X7R 04222 12065C104KAT A
C27 0160-5957 CAP-FXD 47pF +-5% 50V CER COG 51406 GRM39COG470J50*
C28 0160-5959 CAP-FXD 33pF +-5% 50V CER COG 04222 08051A330JATA
C29-C30 0160-6497 CAP-FXD 0.1uF+-10%50V CER X7R 04222 12065C104KAT A
C31 0160-5959 CAP-FXD 33pF +-5% 50V CER COG 04222 08051A330JATA
C33 0160-6497 CAP-FXD 0.1uF+-10%50V CER X7R 04222 12065C104KAT A
C34-C35 0160-6104 2 CAP-FXD 2200pF +-5% 50V CER COG 12340 C1206C222J5GAL
C36 0160-6736 1 CAP-FXD 0.01uF +-10% 50V CER X7R 12340 C1206C103K5RAC
C37 0180-4116 1 CAP-FXD 22uF+-20% 20V TA 12340 T491D226M020AS
C38 0180-4575 1 CAP-FXD 47uF +-20% 20V TA 12340 T491D476K020AS
C39-C40 0180-3751 CAP-FXD 1uF +-20% 35V TA 12340 T491B105M035AS
C41-C42 0160-6940 CAP-FXD 0.33uF +-20% 50V CER Z5U 04222 12105E334MAT A
C43-C44 0180-2980 CAP-FXD 1000uF +-20% 50V AL-ELCTLT S4217
SME50VB102M16X25LL
C45 0160-4065 1 CAP-FXD 0.1uF +-20% 250V PPR-MET(X-CAP) 28480 0160-4065
C46-C47 0160-4183 2 CAP-FXD 1000pF +-20% 250V PPR-MET(Y-CAP) 28480 0160-4183
C48-C49 0180-3962 2 CAP-FXD 33000uF +30%-10% 16V AL-ELCTLT S4217 80D333P016ME2
C50-C51 0160-6225 2 CAP-FXD 0.33uF +-10% 250V POLYE-MET 06127 MKS4-.33/250/10
C52 0160-5967 1 CAP-FXD 100pF +-5% 50V CER COG 12340 C0805C101J5GAC
C53 0160-4535 1 CAP-FXD 1uF +-10% 50V CER X7R 12340 C330C105K5R5CA
C55 0160-4832 CAP-FXD 0.01uF+-10% 100V CER X7R 02010 SA101C103KAAH
CR1-CR2 1906-0291 6 DIODE-DUAL 70V 100mA TO-236 AA 28480 1906-0291
To Next Page
