Chapter 6 Replaceable Parts
E3631-60004 Bottom PCB Assembly
113
6
Reference
Designator
Agilent Part
Number
Qty Description Mfr
Code
Mfr Part Number
CR3 1906-0407 1 DIODE-FW BRDG 400V 1A 71744 DF04S
CR5-CR6 1901-1227 2 DIODE-SWICHING 75V 200mA 6nS TO-236 27014 BAS16
CR9-CR12 1906-0291 DIODE-DUAL 70V 100mA TO-236 AA 28480 1906-0291
CR14 1901-1163 1 DIODE-PWR-S 60V 5A DO-201AD 71744 FE6B
CR15-CR16 1901-1149 2 DIODE-PWR RECT 400V 1A 50NS DO-41 71744 UF4004
CR17 1906-0400 1 DIODE-FW BRDG 600V 6A 71744 GBU8J
VR1-VR2 1826-0774 2 IC PWR MGT-V-REF-FXD 1.223/1.247V TO-92 27014 LM385BZ-1.2
E1 9164-0173 1 ALARM-AUDIBLE PIEZO ALARM PIN TYPE; 25V 51406 PKM24-4A0-1
J1 1252-2161 1 CONN-RECT MICRORBN 24-CKT 24-CONT 00779 554923-2
J2 1252-2266 1 CONN-RECT D-SUBMIN 9-CKT 9-CONT 00779 748959-1
J3 1252-7162 1 CONNECTOR-TIN-PLATED 12PIN 28480 1252-6915
J4 1252-6880 1 CONN-POST-TYPE HDR 8P 27264 22-03-5085
J5 1252-2771 3 CONNECTOR-SGL CONT QDISC-M.25-IN-B 00779 63067-1
J7-J8 1252-2786 4 CONN-POST-TP-HDR 2P 27264 10-63-4027
J9 1251-8363 1 CONN-POST TYPE.156-PIN-SPCG-MTG-EN 27264 09-65-2038
J10-J11 1252-2771 CONNECTOR-SGL CONT QDISC-M.25-IN-B 00779 10-63-4027
J12-J13 1252-2786 CONN-POST-TP-HDR 2P 27264 10-63-4027
Q1 1853-0525 4 TRANSISTOR PNP SI TO-236AA PD=200mW 04713 MMBT2907A
Q2 1853-0041 1 TRANSISTOR PNP SI TO-39 PD=1W FT=60MHz 04713 MM5007
Q3 1855-1660 1 TRANSISTOR MOSFET
N-CHAN E-MODE(TO247AC)
03038 IRFP044N
Q4-Q6 1853-0525 TRANSISTOR PNP SI TO-236AA PD=200mW 04713 MMBT2907A
Q7 1854-1053 1 TRANSISTOR NPN SI SOT-23(TO-236AB) 04713 MMBT2222ALT1
F1-F2 0669-2715 2 RESISTOR-FUSE 1 OHM +-5% 0.5W @70 28480 0669-2715
R1-R3 0699-1318 8 RESISTOR 1K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R4 0699-1330 2 RESISTOR 100K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R5 0699-1318 RESISTOR 1K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R6 0699-1380 2 RESISTOR 3.16K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R7 0699-1374 1 RESISTOR 1.78K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R8 0699-1391 4 RESISTOR 10K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R12 0699-1391 RESISTOR 10K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R13 0699-1425 5 RESISTOR 261 +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R14 0699-1262 4 RESISTOR 2.2K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R15 0699-2145 4 RESISTOR 33K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R16 0699-1444 1 RESISTOR 178K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R17 0699-3661 4 RESISTOR 6.49K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R18-R19 0699-3431 4 RESISTOR 4.99K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R20 0699-1403 2 RESISTOR 31.6K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
R21 0699-1394 1 RESISTOR 14.7K +-1% .125W TKF TC=0+-100 2M627 MCR18FX
