Chapter 1 General Information
Input Power Requirements
11
1
2 Install the correct line fuse. Remove
the power-line voltage selector from the
power-line module.
100 or 115 Vac, 6.3 AT fuse
230 Vac, 3.15 AT fuse
1 Remove the power cord. Remove the
fuse-holder assembly with a flat-blade
screwdriver from the rear panel.
3 Rotate the power-line voltage selector
until the correct voltage appears.
100, 115, or 230 Vac
4 Replace the power-line voltage selector
and the fuse-holder assembly in the rear
panel.
