Chapter 2 Initial Operation
Output Checkout
19
2
6 Ensure that the current can be adjusted from zero to the full rated value.
Adjust the knob until the ammeter indicates 0 amps and then until the ammeter
indicates 20.0 amps* or 7.0 amps**.
7 Turn off the power supply and remove the short from the output.
1
You can use the resolution selection keys to move the blinking digit to the right or
left when setting the current.
Note If an error has been detected during the output checkout procedures, the ERROR
annunciator will turn on.
See "Error Messages" for more information starting on page
123 in chapter 5
*For Agilent E3633A Model **For Agilent E3634A Model
