ESG Family Signal Generators Hardkey and Softkey Reference
Save
User’s Guide 4-95
Select Seq
Press this softkey to choose a sequence for all softkeys which specify a
sequence in this menu. For example, if you want to select sequence 4,
press
Select Seq. The currently selected sequence is displayed in the
active entry area. Change the number to 4 using the up and down
arrow keys, the front panel knob, or enter a 4 using the numeric keypad
and press the
Enter terminator softkey. Sequence 4 is now displayed in
all softkeys which specify a sequence in this menu.
There are 100 registers available (0 through 99) in each of 10 (0 through
9) sequences. You can use these registers in any combination so long as
the total number of registers used does not exceed 100.
NOTE The actual number of states that can be saved may be less if the user
file system has non-instrument state files stored such as sweep/list
sequences or binary files.
Softkey Location:
Save > Select Seq
