Agilent Technologies E4430B User Manual

Front and Rear Panel ESG Family Signal Generators
Front Panel Overview
3-2
User’s Guide
Front Panel Overview
1. EXT 1 INPUT Connecto
r
2. EXT 2 INPUT Connecto
r
3. Help Key
4. Trigger Key
5. LF OUTPUT Connector
6. Mod On/Off Key
7. RF OUTPUT Connector
21. Display
22. Hold Key
23. Softkeys
24. Knob
25. Amplitude Key
26. Frequency Key
27. Save Key
28. Menu Keys
29. Incr Set Key
30. Recall Key
31. DATA Input Connector
32. DATA CLOCK
33. SYMBOL SYNC Input Connector
20. I INPUT Connector
19. Q INPUT Connector
8. RF On/Off Key
9. Numeric Keypad
10. Arrow Keys
11. Return Key
12. Display Contrast Decrease Key
13. Display Contrast Increase Key
14. Local Key
16. Standby LED
17. Line Power LED
15. Preset Key
18. Power Switch
34. PULSE IN Connector

Agilent Technologies E4430B Specifications

General

Brand	Agilent Technologies
Model	E4430B
Category	Portable Generator
Language	English
