Agilent Technologies E4430B User Manual

Front and Rear Panel ESG Family Signal Generators
Rear Panel Overview
3-12
User’s Guide
Rear Panel Overview
4. AUXILIARY INTERFACE Connector
3. SYMBOL SYNC OUT Connector
2. GPIB
1. AC Power
5. DATA CLK OUT Connector
6. SWEEP OUT Connector
7. DATA OUT Connector
8. TRIGGER OUT Connector
9. TRIGGER IN Connector
10. 10 MHz IN Connector
11. 10 MHz OUT Connector
12. PATTERN TRIG IN Connector
13. BURST GATE IN Connector
14. COHERENT CARRIER OUT Connector
16. EVENT 1 Connector
17. EVENT 2 Connector
18. BASEBAND GEN REF IN Connector
19. I OUT Connector
20. Q OUT Connector
21. BER MEAS END Connector
22. BER TEST OUT Connector
23. BER ERR OUT Connector
24. BER NO DATA Connector
25. BER SYNC LOSS Connector
26. BER DATA IN Connector
27. BER CLK IN Connector
28. BER GATE IN Connector
15. ALT PWR IN Connec-
29. 321.4 MHz IN Connector

Agilent Technologies E4430B Specifications

General

Brand	Agilent Technologies
Model	E4430B
Category	Portable Generator
Language	English
