Hardkey and Softkey Reference ESG Family Signal Generators
Utility
4-116 User’s Guide
Data Polarity Neg Pos (Option UN8)
This softkey in the Signal Polarity Setup menu is used to configure the
polarity of the TTL signal at the DATA connector. Pos refers to normal
logic, while Neg refers to inverted logic.
Default Value: Pos
Softkey Location:
Utility > Instrument Adjustment > Signal Polarity Setup >
Data Polarity Neg Pos
Delete All Files
Press this softkey to delete all of the files in the displayed catalog of
files. You will then confirm that you want to delete all of the files in
memory. Press the
Confirm Delete Of All Files terminator softkey and all of
the files are deleted.
CAUTION You cannot recover files after this step. If you change your mind and do
not wish to delete the files, press the Return front panel hardkey instead.
This softkey does not affect the persistent state or calibration
information. If power on mode is set to last, a new last state file will be
created when the instrument idles.
Softkey Location:
Utility > Memory Catalog > Catalog Type > All >
Delete All Files
Delete All <catalog type> Files
Press this softkey to delete all of the files in the displayed catalog of
files of a selected catalog type. You must confirm that you want to delete
all of the files. Press the
Confirm Delete Of <catalog type> Files terminator
softkey to delete all the files of the selected type.
CAUTION You cannot recover files after this step. If you change your mind and do
not wish to delete the files, press the Return front panel hardkey instead.
Softkey Location:
Utility > Memory Catalog > Catalog Type > <catalog type> >
Delete All <catalog type> Files
Delete File
Press this softkey to delete a file in the displayed catalog of files. To
delete a file, first select the file from the displayed list by scrolling
through the list using the front panel knob or up and down arrow keys.
When the desired file is highlighted, press
Delete File. Then press the
Confirm Delete terminator softkey and the file is deleted. You cannot
recover the file after this step. If you have changed your mind and do
not wish to delete the file, press the
Return front panel hardkey instead.
Softkey Location:
Utility > Memory Catalog > Delete File
