Chapter 4
Front-Panel Key and SCPI Command Reference
Measure
167
Front-Panel Key and SCPI Command
Reference
4.3.12 Audio AC Level
Allows the user to switch to the Audio Level measurement.
4.3.12.1 SCPI Remote Commands
:CONFigure:AUDLevel
:INITiate:AUDLevel
:FETCh:AUDLevel[n]?
:MEASure:AUDLevel[n]?
:READ:AUDLevel[n]?
Mode: MRECEIVE
Key Path:
Measure, More
Remote Command: :CONFigure:AUDLevel
Dependencies/Couplings: This key is grayed out when opt 107 is not available.
Notes: This key invokes Audio AC Level measurement.
Example: :CONF:AUDL
Index: n
<Mnemonic>
Results Returned
0 Returns unprocessed real data.
not specified or
n = 1
Returns comma-separated scalar results, in the following order:
Return the audio AC level(V)
Return the audio AC level Ratio(–999 in Normal mode, Ratio: dB or % depending on Ratio Mode
setting)
Ratio Reference Level (V)
Return the audio frequency(Hz)
Return the audio distortion(%)
Return the audio sinad(dB)
