Chapter 3 65
Making Measurements
Mode Setup
Mode Setup
All measurements need to be set up in 3 steps: first at the Mode level, second at the
Measurement level, then finally the result display may be adjusted.
Press
MODE, then all licensed, installed Modes available are show. Press
Measuring Receiver to select Measuring Receiver mode.
Press
Input/Output to adjust the input port and attenuation. You can change the
external audio attenuation by pressing
Ext Aud Atten and entering the appropriate
value and unit. To change the audio input ranging, press
Audio Ranging and select
a range according to your input.
Press
Det/Demod key to adjust detectors, filters.
Press
MEASURE to select a specific measurement to be performed. Press
Frequency Counter or Preset to get the RF frequency before making other
measurements.
Press
Meas Setup to make any adjustments as required to the selected measurement
settings. The settings only apply to this measurement.
Press
Trace/View to select a display format for the current measurement data.
Depending on the mode and measurement selected, some graphical and tabular
data presentations may be not available and
X-Scale or Y-Scale may be grayed out.
NOTE A setting may be reset at any time, and will be in effect on the next measurement
cycle or View.
CAUTION If you make changes to the UUT or measuring receiver settings after you make
your first measurement, press the
Restart key to optimize the measuring receiver
configuration.
Step Primary Key Setup Keys Related Keys
1. Select & set up a
Mode
MODE Mode Setup,
Input/Output,
Det/Demod,
FREQUENCY Channel
System
2. Select & set up
a Measurement
MEASURE Meas Setup Meas Control,
Restart
3. Select & set up a
View of the Results
Trace/View SPAN X Scale,
AMPLITUDE Y Scale
,
Next Window, Zoom
File
, Save
