Chapter 4
Front-Panel Key and SCPI Command Reference
Measurement keys
247
Front-Panel Key and SCPI Command
Reference
4.4.9 Modulation SINAD Measurement
There is only one view available for this measurement.
There are two windows in this view:
• Modulation SINAD Numeric Result Window (upper)
• Modulation SINAD Settings Window (lower)
Table 4-27 Modulation SINAD Numeric Results Window
Name Corresponding Results
Modulation SINAD n=1,1st
Modulation SINAD
Modulation SINAD
Ratio
n=1, 2nd
This result will replace Modulation SINAD when
Display Mode is Ratio
Table 4-28 Modulation SINAD Settings Window
Name Corresponding Results
IF BW Type It can be Auto, Manual or Min
IF BW This value is the IF bandwidth set manually
Detector Selection It can be Peak +, Peak −, Peak +/– 2 or RMS
Peak Hold It can be On or Off
HP Filter It can be None, 50 Hz or 300 Hz
LP Filter It can be None, 3 kHz, 15 kHz, 30 kHz or 300 kHz
De-emphasis Filter It can be None, 25 μs, 50 μs, 75 μs, or 750 μs
