66 Chapter 5
Options and Accessories
Options
233 Measuring Receiver Personality
and PC software
This option allows you to use your PSA, an Agilent power meter and
N5532A Sensor module as a measuring receiver system through the PSA
user interface (UI). It also provides PC software, as an extension of the
built-in measuring receiver personality, offering graphic and remote UI on
an external PC. A sensor module to power meter adapter, N5532A Option
019, is required for use with N1911A/12A power meters. Option 233 is
available in all models.
Requires Option 107 for Audio measurements.
23A AM/FM/PM Triggering for use
with the Measuring Receiver
Personality
Option 233 must be installed before Option 23A
Provides the trigger support in the AM Depth, FM Deviation, and PM
Deviation measurements of the Measuring Receiver personality to detect
the settling time for carrier frequency change. The triggering types
supported are Free Run, Video (IF Envelope), External Front, External
Rear, and RF Burst.
23B CCITT Audio Filter for use with
the Measuring Receiver
Personality
Option 233 must be installed before Option 23B
Adds the CCITT weighting filter, a 30 kHz and an 80 kHz low pass filter,
and a 400 Hz high pass filter to the audio measurements of the Measuring
Receiver personality. (These include Audio Frequency, Audio AC Level,
Audio Distortion, and Audio SINAD.)
235
Not available
for E4447A
80 MHz Digitizer External
Calibration Wizard and License
This calibration software runs on an external PC to generate a file of
correction factors for PSAs with Option 122. You get improved
measurement accuracy using this correction file.
239 EMC Analyzer Personality Adds EMC measurement capability. With the addition of the N9039A RF
Preselector, allows compliant EMC measurements. Selected signal sources
are required for system alignment.
241 Flexible Digital Modulation
Analysis
Provides flexible demodulating analysis for measuring many different
formats of digital modulation, including:
MSK type 1 and type 2
EDGE
QPSK and offset QPSK
8PSK
BPSK
DQPSK and Pi/4 DQPSK
D8PSK
QAM 16, 32, 64, 128, 256
FSK 2, 4, 8 states
Requires Option 122 or 140 for symbol rates > 10 MHz
266 Programming Code
Compatibility Suite
Lets you select one of three different modes that let you use a limited set of
8560 Series, 8566B/8568B, or 8590 Series programming commands.
These modes let you control the PSA Series analyzers with code from
other spectrum analyzer families. When these modes are enabled, the
instruments native SCPI commands are disabled if the remote language
selected is not SCPI.
Option
Number
Name Description
