Chapter 5 67
Options and Accessories
Options
ANE
Enhanced Memory Upgrade For early instruments, replaces existing 48 Mb with 64 Mb memory on
CPU, providing additional memory for storing optional measurement
personalities. The 64 Mb memory was shipped standard in all PSA
instruments with serial numbers
US/MY 42220000.
It is recommended that Option 115 (512 Mb user memory) be purchased to
accommodate a greater number of applications.
AYZ External Mixing Provides the ability to use the HP/Agilent 11970 Series harmonic mixers,
and HP/Agilent 11974 preselected harmonic mixers with the Agilent
E4440A, E4446A, E4447A, or E4448A analyzer to extend the frequency
range to 110 GHz. Operation to 325 GHz is also possible with
non-HP/Agilent mixers. Option AYZ cannot be installed if Option 123 is
installed.
B78 cdma2000 Measurement
Personality
Provides cdma2000 transmitter measurements:
channel power
ACPR
intermodulation
spectrum emission mask
occupied BW
code domain power
modulation accuracy (composite rho)
QPSK EVM
power statistics CCDF
Requires Option B7J hardware.
Requires Option 214 for 1xEV-DV functionality.
B7J Digital Demod Hardware Adds 1 dB step, electronic attenuator in addition to the existing manual
attenuator. This is required for the personality options: BAC, BAE, BAF,
B78, 202, 204, 210, 212, 213, and 214. This option also adds the
functionality of Basic Mode, including the measurements:
spectrum (frequency domain)
waveform (time domain)
BAB
(E4440A
only)
APC 3.5 Input Connector Replaces the standard type-N female connector with an APC 3.5-mm male
connector.
BAC cdmaOne Measurement
Personality
Provides IS-95 and J-STD-008 transmitter measurements:
channel power
modulation accuracy (rho)
code domain power
ACPR
spur close
Requires Option B7J hardware.
Option
Number
Name Description
