20 Chapter 1
Installation and Setup
Printer Setup and Operation
•The Print Setup menu will be displayed with the None key selected and the following message
will appear in the display status line:
Unsupported printer, Printer Type set to None
This indicates that the analyzer has successfully identified the connected printer, but the printer is
not supported by the analyzer. As long as
None is selected in the Printer Type menu, the analyzer
will respond to any print command by displaying the message Printer Type is None in the
display status line.
7. Select the desired paper size by pressing
Print Setup, More, Page Size, then choose the appropriate
page size for which your printer is configured. This setting will remain unchanged with Preset or
Power Cycle.
The factory default page size is
Letter. The page size will be reset to Letter if System, More,
Restore Sys Defaults is executed.
Testing Printer Operation
When you have completed the analyzer’s printer setup, press
Print Setup, Print (Screen) and then press
Print on the front panel. If the printer is ready and the printer setup was successful, a printout of the
analyzer display will be printed. If the printer is not ready, the message Printer Timeout will appear
on the analyzer display. Printer Timeout will remain on the display until the printer is ready or until
you press
ESC to cancel the printout request.
NOTE There may be some small discrepancies in the color mapping of the analyzer display to
your color printer. Due to differences in display and printer technologies, the default
display colors do not map exactly to the printer colors. For example trace 1 is yellow on
your analyzer display while it maps to green on your printer.
To Next Page
