Chapter 1 7
Installation and Setup
Initial Inspection
Initial Inspection
Inspect the shipping container and the cushioning material for signs of stress. Retain the shipping
materials for future use, as you may wish to ship the analyzer to another location or to Agilent
Technologies for service. Verify that the contents of the shipping container are complete. The following
table lists the items shipped with the analyzer.
Item Description
Accessories
Adapter, Type-N (m) to BNC (f) Two adapters are shipped with Option 1DN.
Adapter, Type-N (m) to SMA (f) Shipped only with Option 1DN for Agilent E7402A, E7403A,
E7404A, and E7405A. Not shipped with Option BAB.
Adapter, APC 3.5 (f) to APC 3.5 (f) Shipped only with Option BAB.
Adapter, BNC (f) to SMA (m) Shipped only with Option BAB.
Cable, BNC (m) to BNC (m), 203 mm Shipped only with Agilent E7402A, E7403A, E7404A, and E7405A.
Cable, SMA (m) to Type-N (m), 220 mm Shipped only with Option 1DN for Agilent E7402A, E7403A,
E7404A, and E7405A.
Power Cable (See Table 1-3. on page 12) Connection for power source.
Standard Documentation Set
Getting Started Guide Covers unpacking and setting up the analyzer, analyzer features, and
how to make a basic measurement. Includes information on options
and accessories, and what to do if you have a problem.
User’s Guide Describes analyzer features in detail, including front-panel key
descriptions.
Programmer’s Guide Describes basic spectrum analyzer programming information, and
SCPI command descriptions.
Spectrum Analyzer Measurement Guide Provides details on how to measure various signals, and how to use
catalogs and files.
EMC Measurement Guide Provides details on how to make EMC measurements.
Specifications Guide Documents specifications, safety, and regulatory information.
Instrument Messages and Functional Tests Includes instrument messages (and suggestions for troubleshooting
them), and manual functional tests.
Programming Conversion Guide Describes SCPI programming command compatibility for 8590, ESA
series analyzers.
Documentation CD-ROM Includes the documents in the standard set (listed above). You can
view and print the information as needed. See the CD-ROM jacket for
installation information.
