Chapter 1 9
Installation and Setup
Power Requirements
Power Requirements
The only physical installation of your Agilent spectrum analyzer is a connection to a power source.
Line voltage does not need to be selected.
WARNING Failure to ground the analyzer properly can result in personal injury. Before turning
on the analyzer, you must connect its protective earth terminals to the protective
conductor of the main power cable. Insert the main power cable plug into a socket
outlet that has a protective earth contact only. DO NOT defeat the earth-grounding
protection by using an extension cable, power cable, or autotransformer without a
protective ground conductor.
If you are using an autotransformer, make sure its common terminal is connected to
the protective earth contact of the power source outlet socket.
This is a Safety Class 1 Product (provided with a protective earth ground
incorporated in the power cord). The mains plug shall only be inserted in a socket
outlet provided with a protective earth contact. Any interruption of the protective
conductor inside or outside of the product is likely to make the product dangerous.
Intentional interruption is prohibited.
CAUTION The Mains wiring and connectors shall be compatible with the connector used in the
premise electrical system. Failure, to ensure adequate earth grounding by not using the
correct components may cause product damage, and serious injury.
CAUTION VENTILATION REQUIREMENTS: When installing the product in a cabinet, the
convection into and out of the product must not be restricted. The ambient temperature
(outside the cabinet) must be less than the maximum operating temperature of the product
by 4°C for every 100 watts dissipated in the cabinet. If the total power dissipated in the
cabinet is greater than 800 watts, then forced convection must be used.
This instrument has auto-ranging line voltage input, be sure the supply voltage is within
the specified range and voltage fluctuations do not to exceed 10 percent of the nominal
supply voltage.
NOTE For more information regarding analyzer specifications, see the Specifications guide.
