40 Chapter 3
Making a Basic Measurement
This chapter is divided into the following sections:
•“Using the Front Panel” on page 41.
•“Presetting the Spectrum Analyzer” on page 42.
•“Viewing a Signal” on page 43.
CAUTION Ensure that the total power of all signals at the analyzer input does not exceed +30
dBm (1 watt).
Basic Assumption
The material in this chapter is presented with the assumption that you understand the analyzer’s front
and rear panel layout, and display annotations. If you do not, refer to “Front and Rear Panel Features”
on page 23.
