34 Agilent 1200 Preparative Pump User Manual
3 Installing the Pump
Optimizing the Stack Configuration
Optimizing the Stack Configuration
If your preparative pump is part of a complete Agilent 1200 Series system, you
can ensure optimum performance and minimum delay volume by installing
the following configuration.
• Figure 5 on page 34 and Figure 6 on page 35 show the configuration
recommended for the pump in a UV based system.
Preparative System
Figure 5 Recommended Stack Configuration -Preparative System (Front View)
