Agilent Technologies N5700 Series

Appendix B Verification and Calibration
102 Series N5700 User’s Guide
Test Record Form – Agilent N5742A and N5762A
Agilent N5742A and N5762A Report No _______________ Date __________________
Description Model Minimum Specs. Results Maximum Specs.
Voltage Programming & Readback
Minimum Voltage Vout
Measurement Readback
High Voltage Vout
Measurement Readback
Both
Both
Both
Both
0 mV
Vout − 8 mV
7.992 V
Vout − 16 mV
__________
__________
__________
__________
+20 mV
Vout + 8 mV
8.008 V
Vout + 16 mV
CV Load Effect Both − 2.8 mV __________ + 2.8 mV
CV Source Effect Both − 2.8 mV __________ + 2.8 mV
CV Ripple and Noise
peak-to-peak
rms
Both
Both
N/A
N/A
__________
__________
60 mV
8 mV
Transient Response
Voltage @ 1.5ms Both
− 40 mV
__________ + 40 mV
Current Programming & Readback
Minimum Current Iout
Measurement Readback
High Current Iout
Measurement Readback
N5742A
N5762A
N5742A
N5762A
N5742A
N5762A
N5742A
N5762A
0 mA
0 mA
Iout − 270 mA
Iout − 495 mA
89.82 A
164.67 A
Iout − 360 mA
Iout − 660 mA
__________
__________
__________
__________
__________
__________
__________
__________
+ 452 mA
+ 827 mA
Iout + 270 mA
Iout + 495 mA
90.18 A
165.33 A
Iout + 360 mA
Iout + 660 mA
CC Load Effect N5742A
N5762A
− 23 mA
− 38 mA
__________
__________
+ 23 mA
+ 38 mA
CC Source Effect N5742A
N5762A
− 11 mA
− 18.5 mA
__________
__________
+ 11 mA
+ 18.5 mA
Test Description N5742A Settings N5762A Settings
Voltage Programming & Readback, Min Voltage ≤16 mV, 360 mA ≤16 mV, 660 mA
Voltage Programming & Readback, High Voltage 8 V, 360 mA 8 V, 660 mA
CV Load Effect, Source Effect, Ripple and Noise 8 V, 90 A 8 V, 165 A
Transient Response 8 V, from 9 A to 81A 8 V, from 16.5 A to 148.5A
Current Programming & Readback, Min Current 360 mA, 8 V 660 mA, 8 V
Current Programming & Readback, High Current 90 A, 8 V 165 A, 8 V
CC Load Effect, Source Effect 90 A, 8 V 165 A, 8 V
Load Requirements N5742A N5762A
Current shunt 0.01Ω 100 A 0.001Ω 300 A
Agilent N3300 Electronic load modules 2 – N3305A 3 – N3305A
Fixed Resistor for CV Ripple and Noise 0.09Ω 1kW 0.04Ω 2kW
