Verification and Calibration Appendix B
Series N5700 User’s Guide 103
Test Record Form – Agilent N5743A and N5763A
Agilent N5743A and N5763A Report No _______________ Date __________________
Description Model Minimum Specs. Results Maximum Specs.
Voltage Programming & Readback
Minimum Voltage Vout
Measurement Readback
High Voltage Vout
Measurement Readback
Both
Both
Both
Both
0 mV
Vout − 12.5 mV
12.4875 V
Vout − 25 mV
__________
__________
__________
__________
+ 31.25 mV
Vout + 12.5 mV
12.5125 V
Vout + 25 mV
CV Load Effect Both − 3.25 mV __________ + 3.25 mV
CV Source Effect Both − 3.25 mV __________ + 3.25 mV
CV Ripple and Noise
peak-to-peak
rms
Both
Both
N/A
N/A
__________
__________
60 mV
8 mV
Transient Response
Voltage @ 1.5ms
Both
− 62 mV
__________
+ 62 mV
Current Programming & Readback
Minimum Current Iout
Measurement Readback
High Current Iout
Measurement Readback
N5743A
N5763A
N5743A
N5763A
N5743A
N5763A
N5743A
N5763A
0 mA
0 mA
Iout − 180 mA
Iout − 360 mA
59.88 A
119.76 A
Iout − 240 mA
Iout − 480 mA
__________
__________
__________
__________
__________
__________
__________
__________
+ 302 mA
+ 601 mA
Iout + 180 mA
Iout + 360 mA
60.12 A
120.24 A
Iout + 240 mA
Iout + 480 mA
CC Load Effect
N5743A
N5763A
− 17 mA
− 29 mA
__________
__________
+ 17 mA
+ 29 mA
CC Source Effect
N5743A
N5763A
− 8 mA
− 14 mA
__________
__________
+ 8 mA
+ 14 mA
Test Description N5743A Setting N5763A Setting
Voltage Programming & Readback, Min Voltage ≤25 mV, 240 mA ≤25 mV, 480 mA
Voltage Programming & Readback, High Voltage 12.5 V, 240 mA 12.5 V, 480 mA
CV Load Effect, Source Effect, Ripple and Noise 12.5 V, 60 A 12.5 V, 120 A
Transient Response 12.5 V, from 6 A to 54A 12.5 V, from 12 A to 108 A
Current Programming & Readback, Min Current 240 mA, 12.5 V 480 mA, 12.5 V
Current Programming & Readback, High Current 60 A, 12.5 V 120 A, 12.5 V
CC Load Effect, Source Effect 60 A, 12.5 V 120 A, 12.5 V
Load Requirements N5743A N5763A
Current shunt 0.01Ω 100 A 0.001Ω 300 A
Agilent N3300 Electronic load modules 2 – N3305A 3 – N3305A
Fixed Resistor for CV Ripple and Noise 0.21Ω 1kW 0.10Ω 2kW
