Agilent Technologies U1253B Quick Start Guide

U1253B Quick Start Guide
Square Wave Output
1 Turn the rotary switch to .
2 Press to select duty cycle (%) on
the primary display.
3 The default square wave frequency is 600
Hz as shown by the secondary display,
with a 50% duty cycle as shown by the
primary display.
4 Press or to scroll through the
available frequencies (there are 28
frequencies to choose from).
5 Press or to adjust the duty cycle.
The duty cycle can be set from 0.390625%
to 99.609375%, in steps of 0.390625%.
The displayed duty cycle has a resolution
of 0.001%.
