14 03-914852-00:4
ACTIVE
METHOD
EDIT
METHOD
CTRL
RUN
TIME
END
TIME
Injector Ports To Use With CP-8400:
Syringe Size:
EDIT CP-8400 SETUP
Both
10 µl
Save and Exit
Calibrate
Automation Configuration Select the Calibrate softkey to begin the CP-8400
(or CP-8410) calibration process.
Injector Ports to use with CP-8400/8410 – Available entries: Position 1,
Position 2, Both. If one injector is installed on your CP-3800, make certain to
specify the correct injector in the “Injector Ports to use with CP-8400 (or
CP-8410)” selection. An incorrect setting may cause the CP-8400/8410 to
inadvertently inject into the top cover resulting in damage to the syringe and the
top cover. The CP-8400/8410 syringe tower rotates clockwise to reach the
injectors. The first injector the tower will encounter is referred to as Position 1.
The second injector is Position 2. Select the Both setting if you have two injectors
that you wish to use with the CP-8400/8410. Note that selecting both allows the
CP-8400/8410 to use two injection volumes when dual/duplicate mode is used. If
you configure a single injector, you will see a single injection volume in the
automation tables.
Syringe Size – Available entries: 5 µ
µµ
µL, 10 µ
µµ
µL and 100 µ
µµ
µL. (Note that this field
is not used when the Auto Sampler is in the SPME mode and will be dashed out).
Enter the syringe volume you will install and use with your CP-8400/8410. The
CP-3800 will use this value to set the correct entry selections and any needed
internal settings to correctly use the indicated syringe size. Incorrectly setting this
parameter may cause poor operation but will not harm either the GC or the
AutoSampler.
If you are simply changing a syringe with a different volume syringe you can
press Save and Exit at this point to accept the new syringe size.
