Technical Information
RS 232/RS 485 communication description
Examples:
Command: START
Source: PC
Destination: Controller
02 80 30 30 30 31 31 03 42 33
STX ADDR WINDOW WR ON ETX CRC
Source: Controller
Destination: PC
02 80 06 03 38 35
STX ADDR ACK ETX CRC
Command: STOP
Source: PC
Destination: Controller
02 80 30 30 30 31 30 03 42 32
STX ADDR WINDOW WR OFF ETX CRC
Source: Controller
Destination: PC
02
80
06
03
38
35
STX ADDR ACK ETX CRC
164/178 TwisTorr 304 FS on board Controller User Manual / 87-901-028-01 (C)
