RS 232/RS 485 communication description
Window-Meanings
Window-Meanings
N. Read/Write Datatype Description Admitted Values
000 R/W L Start/Stop (in remote mode
the window is a read only)
Start = 1
Stop = 0
008 R/W L Remote (default) or Serial
configuration
Remote = 1
Serial = 0
(default = 1)
100
R/W
L
Soft Start
(write only in Stop condition)
YES = 1
NO = 0
101 R/W N Set Point type 0 = Frequency
1 = Current
2 = Time
(default = 0)
102 R/W N Set Point threshold (expressed
in Hz, mA or s)
(default = 867)
103 R/W N Set Point delay: time between
the pump start and the set
point check (seconds)
0 to 99999
(default = 0)
104 R/W L Set Point signal activation
type: the signal can be "high
level active" or "low level
active"
0 = high level
active
1 = low level
active
(default = 0)
105
R/W
N
Set point hysteresis (in % of
threshold)
0 to 100
(default = 2)
106
R/W
L
Water cooling
0 = NO
1 = YES
107 R/W L Active Stop (write only in
stop)
0 = NO
1 = YES
166/178 TwisTorr 304 FS on board Controller User Manual / 87-901-028-01 (C)
