Electrical Interfaces
AGD301 Product Manual Rev.2.0 Page 44
Pin # Name Software
Representation
Description
8 GND GND for 5V and differential signals
9 Bi-Dir_Diff_IO_6+ DInPortHigh.bit(1)
DOutPort.bit(22)
Bi-directional differential I/O 6+
Software configurable:
BiDirConfig.bit(0) = 0 for input
BiDirConfig.bit(0) = 1 for output
10 Bi-Dir_Diff_IO_6- Bi-Directional differential I/O 6-
11 Digital_Output_10 DOutPort.bit(9) Isolated digital output 10,
programmable sink or source
12 Digital_Output_11 DOutPort.bit(10) Isolated digital output 11,
programmable sink or source
13 Digital_Output_12 DOutPort.bit(11) Isolated digital output 12,
programmable sink or source
14 Digital_Output_13 DOutPort.bit(12) Isolated digital output 13,
programmable sink or source
15 Digital_Output_14 DOutPort.bit(13) Isolated digital output 14,
programmable sink or source
16 Digital_Output_15 DOutPort.bit(14) Isolated digital output 15,
programmable sink or source
17 Digital_Output_16 DOutPort.bit(15) Isolated digital output 16,
programmable sink or source
18 Digital_Output_17 DOutPort.bit(16) Isolated digital output 17,
programmable sink or source
19 Bi-Dir_Diff_IO_2+ DInPort.bit(28)
DOutPort.bit(18)
Bi-directional differential I/O 2+
Software configurable:
BiDirConfig.bit(0) = 0 for input
BiDirConfig.bit(0) = 1 for output
20 Bi-Dir_Diff_IO_2- Bi-Directional differential I/O 2-
21 Bi-Dir_Diff_IO_4+ DInPort.bit(30)
DOutPort.bit(20)
Bi-directional differential I/O 4+
Software configurable:
BiDirConfig.bit(0) = 0 for input
BiDirConfig.bit(0) = 1 for output
22 Bi-Dir_Diff_IO_4- Bi-directional differential I/O 4-
23 GND GND for 5V and differential signals
24 Analog_Output_4 AOutPort[4] Analog output 4, +/-12V, 16 bits
25 Bi-Dir_Diff_IO_5+ DInPortHigh.bit(0)
DOutPort.bit(21)
Bi-directional differential I/O 5+
Software configurable:
BiDirConfig.bit(0) = 0 for input
BiDirConfig.bit(0) = 1 for output
26 Bi-Dir_Diff_IO_5- Bi-directional differential I/O 5-
