Electrical Interfaces
AGD301 Product Manual Rev.2.0 Page 45
Pin # Name Software
Representation
Description
27 Bi-Dir_Diff_IO_7+ DInPortHigh.bit(2)
DOutPort.bit(23)
Bi-directional differential I/O 7+
Software configurable:
BiDirConfig.bit(0) = 0 for input
BiDirConfig.bit(0) = 1 for output
28 Bi-Dir_Diff_IO_7- Bi-directional differential I/O 7-
29 Bi-Dir_Diff_IO_8+ DInPortHigh.bit(3)
DOutPort.bit(24)
Bi-directional differential I/O 8+
Software configurable:
BiDirConfig.bit(0) = 0 for input
BiDirConfig.bit(0) = 1 for output
30 Bi-Dir_Diff_IO_8- Bi-directional differential I/O 8-
31 Digital_Output_Common
_Power (10 to 13)
Common power pin for isolated digital
outputs 10 to 13
32 Digital_Output_Common
_Return (10 to 13)
Common power return pin for isolated
digital outputs 10 to 13
33 Digital_Output_Common
_Power (14 to 17)
Common power pin for isolated digital
outputs 14 to 17
34 Digital_Output_Common
_Return (14 to 17)
Common power return pin for isolated
digital outputs 14 to 17
35 IO_PWR I/O power supply, connected internally
to X7: I/O PWR pin 1
36 IO_PWR_RTN I/O power supply, connected internally
to X7: I/O PWR pin 2
Connector manufacturer 3M
Mating connector part number 10136-3000PE + 10336-52F0-008
Wiring 26 AWG, insulation rated for 100V
Note – 5V supply limitation
The 5V supply provided at pin 7 is limited to 0.5A. The maximum total current provided
by all the 5V pins in the product is limited to 1.5A.
