Electrical and Mechanical Specifications
AGD301 Product Manual Rev.2.0 Page 9
Mechanical Specifications
Feature Specification
Unit dimensions (max) H=57 mm, W=188 mm, D=105 mm
Package dimensions H=70 mm, W=235 mm, D = 145 mm
Unit weight 0.4 kg
Shipping weight 0.5 kg
Figure 3. Product Dimensions (mm)
