Electrical and Mechanical Specifications
AGD301 Product Manual Rev.2.0 Page 8
I/O Specifications
Feature Specification
Power supply for optically isolated
I/Os
Voltage: 5–28 VDC
Optically isolated digital inputs Type: PNP/NPN
Propagation delay: 10 µs
Max. frequency: 100 kHz
Functionality: limit switches, home, captures, start motion,
gain scheduling, and others
Optically isolated digital outputs Type: PNP/NPN
Max current: 0.5A (for NPN type), 0.3A (for PNP type)
Propagation delay: 10 µs
Max. frequency: 100 kHz
Functionality: alarm, in-position, event (PEG), and others
Bi-directional differential I/O Hardware: Differential RS422
Termination: 120 Ω
Propagation delay: 100 ns
Max. frequency: 5 MHz
Direction: Input or output, set by Agito PCSuite
Functionality: Any differential input or output functionality.
Analog inputs Operational voltage: ±12V
Resolution: 12 bit or 16 bit
Analog outputs Operational voltage: ±12V
Resolution: 16 bit
Static brake output Operational voltage: 24V
Maximum current: 3A
