28 agria Grassland Mower 5100
5. Maintenance
5
5
Locking bolts on steering handle
To ensure the steering handle moves easily when ad-
justed to the side:
l Apply some bio-lubricating oil through the hole at
least once per year or after cleaning the machine with
the pressure washer.
l Apply some bio-lubricating oil to the bearing on the
mowing drive clutch lever (B/4) through the hole at
least once per year or after cleaning the machine with
the pressure washer.
Drive-wheels
l Check the tyre pressure periodically. In particular,
ensure that both tyres have equal pressures to give
smooth riding.
l Attach the wheels with the pointed part of tread
lugs showing in travel direction (seen from above) to
obtain full traction.
l Watch the wheel shaft for grass winding
around it and remove the grass, if neces-
sary, by removing the wheels.
Wheel Shaft
Apply bio-lubricating grease to the wheel
shaft around the hub each time the ma-
chine was cleaned with a pressure washer
or at least once per year.
Mowing Attachment
The cutter bar is exposed to extreme strain. There-
fore, it evidently must be maintained and adjusted with
special care.
l Each time before you take up operation and at
intervals of 8 operating hours, lubricate all gliding parts
with bio-lubricating grease or bio-lubricating oil.
l At intervals of approximately 30 minutes of opera-
tion re-tighten all nuts and bolts on the mowing drive
and cutter bar (especially on the knife driver).
