Agria 5100 Rabbit - Air Filter Cleaning and Replacement

32 agria Grassland Mower 5100
5. Maintenance
1 Air filter cover
2 Snap mechanism
3 Filter element
4 Latches
5
5
Air Filter
Clean the air filter insert at 3-month in-
tervals but not later than 25 operating
hours (earlier in very dusty conditions).
To do this, proceed as follows:
l Clean the air filter and its surround-
ing area.
l Open the snap mechanism (2), fold
down the filter cover (1) and remove it.
l Remove the paper element (3).
l Tap the element against a smooth
surface or blow compressed air against
the inside of the filter.
Never brush the filter because this
would press the dirt into the fibres.
l Replace the filter element if it is ex-
tremely dirty.
l Inspect the filter element carefully for
holes or other damage and replace it if
necessary.
l Replace the filter element
l Attach the cover and snap the latches
(4) into place.
I
Do not wash the paper element
(tap it or blow it out)
