3.1) Removing/tting cheek pads

To remove the cheek pads, hold them in front near the

chin guard and pull them in the direction of the arrow

to free them from the press studs (1). Slide the plastic

ap out of its position and remove the cheek pads (2).

To ret the cheek pads, slide them into the helmet,

slide the plastic ap into position on the side of the

helmet (3) and fasten them into place with the press

studs (4).

Make sure that the cheek pads are properly fastened

to the helmet.

3) INTERNAL COMPONENTS

Crown pad

Cheek pads

VVVVVV

1 2

3 4

Questions and Answers:

Need help?

Do you have a question about the AGV K-5 Jet and is the answer not in the manual?

AGV K-5 Jet Specifications

General

Liner	Removable and washable
Safety Standard	ECE 22.05
Ventilation	Adjustable front and rear vents
Weight	Approx. 1350g
Chin Strap	Micrometric
Shell Material	CAF (Carbon-Fiberglass)
