MXG 1.2 Strada - MXP Strada - MXS 1.2 Strada
1  MX STRADA SERIES IN A FEW WORDS
2  WHAT IS IN THE KIT?
3  POWERING
4
 WHAT YOU CAN DO VIA KEYBOARD
4
.1  SET DATE/TIME
4
.2  SET BACKLIGHT
4.3  SET VIDEO INPUT
4.4  COUNTERS MANAGEMENT
4.5  GPS & TRACKS MANAGEMENT
4.6  SYSTEM INFORMATION
5  MX STRADA SERIES AND THE PC
5.1  CONNECTION TO THE PC
5.2  CONFIGURATION OF MX STRADA SERIES
5.2.1  CHANNELS CONFIGURATION
5.2.2  ECU CONNECTION AND CONFIGURATION
5.2.3  CAN2 STREAM CONFIGURATION
5.2.4  CAN EXPANSIONS CONFIGURATION
5.2.5  MATH CHANNELS CONFIGURATION
5.2.6  STATUS VARIABLES CONFIGURATION
5.2.7  PARAMETERS CONFIGURATION
5.2.8  SHIFT LIGHTS AND ALARMS CONFIGURATION
5.2.9  TRIGGER COMMANDS CONFIGURATION
5.2.10  ICONS MANAGER CONFIGURATION
5.2.11  DISPLAY CONFIGURATION
5.2.12  SMARTYCAM STREAM SETTING
5.2.13  CAN OUTPUT CONFIGURATION
5.3  MANAGING A TRACK ON MX STRADA SERIES WITH RACE STUDIO 3
5.4  ECU DRIVER BUILDER
5.5  THE DEVICE WINDOW
5.5.1  LIVE MEASURES LAYER
5.5.2  ONLINE VALUE FORCING
6  ON THE TRACK
7  DATA RECALL
8  NEW FIRMWARE UPGRADE
9  RPM
9.1  RPM FROM ECU
9.2  RPM VIA A 550V SQUARE WAVE OR COIL 150400V
10  CONNECTION WITH THE EXPANSIONS
10.1  REAR CAMERAS CONNECTION AND MANAGEMENT
11  TECHNICAL SPECIFICATIONS AND DRAWINGS
