MX STRADA SERIESCHAPTER 5
When all channels set the configuration is finished:
n
press “Save” on the page top keyboard
n
press “Transmit” to transmit the configuration to MX Strada series
With Track Manager function of Race Studio 3 tracks can be created, deleted and modified
transmitted and received to/from MX Strada series. Press “Tracks” icon.
Please remember: an optional GPS08 Module is needed.
The main page is divided in three columns; on the left:
n
on top, the filters that allow to collect many tracks following customized criteria; by default,
all tracks are shown (light blue “All Tracks” filter in the image below).
n
bottom left, the connected devices in the image, “MXS Strada ID 5302808”)
The column in the middle shows:
n
on top a fast search bar, that allows to select the tracks which satisfy your personal research
criteria; pressing “?” a pop-up window explains research criteria (highlighted in red below),
to say:
n
long name is the name in bold in each track box
n
short name is the track name shown on the display of MX Strada series and is the
name shown top right of each track box
n
track city is the name of the city the track is located in
n
all the tracks listed in Race Studio 3 database. It automatically updates at start up if a
connection to the Internet is available.
The column on the Right shows:
n
the data sheet of the track you are mousing over.
5.3 Managing a track on MX Strada series with
Race Studio 3
