3 Powering
The power is managed by two pins of the
14 pins connector:
n
Pin 1: Power (9-15 Volts)
n
Pin 2: Ground
They must be connected as shown in the
following diagram.
MX Strada series needs to be configured via
software but there are some functions you
can manage via the device lateral buttons.
CHAPTER 4
10 11
MX STRADA SERIES
4 What you can do via keyboard
CHAPTER 3
