Aiphone AX-248C User Manual

- 6 -
1-4
Door station
a. Audio door station
b. Video door station
c. Surface mount type
d. Flush mount type
e. Without proximity card reader
f. With proximity card reader
g. Standard type
h. Vandal-resistant type
∗ For North America only
1-3
External integration example
[1] CCTV system
[2] Access control system
[3] AC transformer PT1210N (AC 12V, 10VA, for North America
only)
[4] Electric door strike EL-9S
a. System log (RS-232C)
b. Camera switching
c Video signal
d. Remote door release signal (RS-232C)
e. Door release dry contact (N/O or N/C programmable)
f. Door release record
g. Card ID / Data (Wiegand)
[1]
[2]
[3]
[4]
PC
AX-084C
AX-248C
c
a
d
b
c
e
g
e
fd
AX-DM IE-JA
IE-SS(SOP)
AX-DV AX-DVF
AX-DV-P AX-DVF-P
IF-DA
a
cdcd
b
e
f
g
h
g
h
