Aiphone GT SERIES Installation Manual

11
1
2
1 Mount the unit on the included DIN rail. Click the unit into place.
2 When removing the unit, pull the lock release lever down.
The GT-MCX cannot be mounted directly to a wall surface.
DIN rail
DIN rail (included)
Lock release lever
Mounting the multi building control unit GT-MCX
3-2
MOUNTING

Aiphone GT SERIES Specifications

General

Hands-free Communication	Yes
Door Release	Yes
Video	Color
Weather Resistance	IP54
System Type	Video Intercom
Display	Color LCD
Camera	Integrated CCD camera
Wiring	2-wire
Expandable	Yes, up to 500 units
Mounting	Surface or flush mount
Capacity	Up to 500 stations
Operating Voltage	24V DC
Operating Temperature	-10°C to 60°C
