Wire diameter
Wiring distance
0.65 mm
(22 AWG)
0.8 mm
(20 AWG)
1.0 mm
(18 AWG)
[1]
GT-MCX - power supply 3 m (10') 5 m (16') 5 m (16')
[2]
GT-MCX - DP
*1
50 m (165') 50 m (165') 50 m (165')
[3]
GT-MCX - GT-VBC 50 m (165') 50 m (165') 50 m (165')
[4]
GT-MCX - GT-VBX 50 m (165') 50 m (165') 50 m (165')
[5]
GT-MCX - switching hub CAT5e/6 cable 100 m (330')
*2
[6]
GT-VBC - farthest GT-MKB-N 100 m (330') 150 m (490') 150 m (490')
[7]
GT-BC - DP
*1
3 m (10') 5 m (16') 5 m (16')
[8]
Entrance station - GT-VBC 150 m (490') 300 m (980') 300 m (980')
[9]
Entrance station - GT-VBX 150 m (490') 300 m (980') 300 m (980')
[10]
GT-BCXB-N - GT-BC 150m (490') 300 m (980') 300 m (980')
[11]
GT-BC - power supply *3 3 m (10') 5 m (16') 5 m (16')
[12]
GT-VBC - power supply *3 3 m (10') 5 m (16') 5 m (16')
[13]
GT-MKB-N - power supply *3 100 m (330') 150 m (490') 150 m (490')
[14]
Entrance station - power supply *3 150 m (490') 300 m (980') 300 m (980')
[15]
GT-BCXB-N - power supply *3 3 m (10') 5 m (16') 5 m (16')
Audio only main section audio [R1, R2] total wiring distance per
common line (maximum 2 "common" trunk lines)
1650 m (5400') 2500 m (8200') 2500 m (8200')
*1: DP = Distribution Point (Not provided by Aiphone except for Europe and North America.)
*2:
Do not route a CAT5e/6 cable outdoors from a multi-building control unit directly. When routing a CAT5e/6 cable outdoors from a switching hub, use a
model that supports outdoor wiring.
*3: When powering two or more devices with one power supply, separate the cables near the power supply.
* GT-MCX includes the Chinese RoHS paper.
2 COMPONENTS
English, French installation manual (this manual)
Multi-building control unit
GT-MCX
SYSTEM CONFIGURATIONS
* A mounting bracket is attached to the product.
