Installation Data
Minimum Clearances
A vertical air discharge unit is recommended for installation in windy locations or wherever a
horizontal airow would be obstructed.
3000mm
500mm
500mm500mm
500mm
500mm
500mm
500mm
CR12 - CR165 50/60HzCONDENSERS
11
Condenser Technical Manual 6666879 V2_02_2020
Installation
