Operation
SP200, SP300, AllPro Mustang 2400,
Mustang 3100
3A0994E
EN
For portable spray application of architectural paints and coatings. For professional use
only.
See page 2 for model information, including maximum working pressure and approvals.
Important Safety Instructions
Read all warnings and instructions in this
manual. Save these instructions.
SP200/Mustang 2400 Model: Use water based or
mineral-spirit type material only. Do not use materials
having flash points lower than 70°F (21°C). This
includes, but is not limited to, acetone, xylene,
toluene, or naptha. For more information about your
material request MSDS from distributor or retailer.
SP200 Model 24F557
Mustang 2400 Model 24F559
SP300 Model 24F558
Mustang 3100 Model 24F560
ti111304a
ti11305a

Table of Contents

Other manuals for AIRLESSCO SP200

Preview: Repair And Parts
Repair And Parts38 pages

Questions and Answers

  • M
    mitchelljohnAug 17, 2025
    Why does my AIRLESSCO SP200 Paint Sprayer pump cycle but not build up pressure?
    • A
      Amanda RobinsonAug 17, 2025
      If your AIRLESSCO Paint Sprayer pump cycles but doesn't build up pressure, it could be due to several reasons. First, ensure the pump is properly primed. Check the inlet screen and suction tube to confirm they are free of clogs and fully immersed in the paint. Also, examine the suction tube for any leaks, tightening the connection or replacing the tube if necessary.
  • B
    Bridget PetersonAug 20, 2025
    How to fix AIRLESSCO SP200 pump that does not prime?
    • A
      Andrea LawrenceAug 20, 2025
      To fix an AIRLESSCO Paint Sprayer that doesn't prime, first, ensure the Prime/Spray Valve is in the PRIME position. Check the inlet screen for clogs and make sure the suction tube is immersed in the fluid. If that doesn't work, try priming the pump with water or solvent-based flushing fluid. If the inlet valve check ball is stuck, try dislodging it with a pencil or power flushing the sprayer. Also, tighten the suction tube connection and inspect for leaks.
  • M
    Michael WilliamsonAug 22, 2025
    What to do if AIRLESSCO SP200 sprays dribbles or spurts?
    • P
      Patrick VegaAug 22, 2025
      If your AIRLESSCO Paint Sprayer pump cycles, but the paint only dribbles or spurts when the spray gun is triggered, it may be due to low pressure. Increase the pressure by slowly turning the Pressure Control Knob clockwise. Also, the spray tip may be clogged and needs unclogging.
  • L
    lisalandryAug 25, 2025
    How to improve spray pattern of AIRLESSCO SP200 Paint Sprayer?
    • C
      Cathy RoseAug 26, 2025
      If your AIRLESSCO Paint Sprayer can't achieve a good spray pattern even at maximum pressure, first check that the reversible spray tip is in the SPRAY position. If it's not, rotate the arrow-shaped handle on the spray tip to point forward. Also, clean the inlet screen. If the problem persists, thin the material.
  • B
    brett06Aug 28, 2025
    What to do if AIRLESSCO spray gun stopped spraying?
    • M
      michaelhoffmanAug 28, 2025
      If your AIRLESSCO spray gun has stopped spraying, first, check the suction tube connection and tighten it if it's leaking. Inspect for cracks or vacuum leaks. Also, unclog the spray tip.
  • S
    Savannah BruceAug 31, 2025
    What to do if AIRLESSCO SP200 motor doesn't run?
    • J
      Jeremy HerreraAug 31, 2025
      If your AIRLESSCO Paint Sprayer's motor doesn't run, even when plugged in and the power switch is on, several factors could be at play. First, check if the pressure is set to zero and increase it by turning the pressure control knob clockwise. Ensure the electric outlet is working by testing it with another device or trying a different outlet, and reset the circuit breaker or replace the fuse if necessary. Inspect the sprayer's electric cord and any extension cords for damage, replacing them if needed. Lastly, if the sprayer has been exposed to freezing temperatures, thaw it completely before use to prevent damage. If paint has hardened inside, it may require professional servicing.
  • A
    allisonmeyerSep 2, 2025
    Why AIRLESSCO SP200 motor is hot and runs intermittently?
    • R
      Ryan PalmerSep 2, 2025
      If your AIRLESSCO Paint Sprayer motor is hot and runs intermittently, with automatic shut-offs due to excessive heat, ensure that the vent holes in the enclosure are not plugged and the sprayer is open to air. If you're using an extension cord, replace it, making sure it's not too long or of insufficient gauge. If using an electrical generator, ensure it has a proper voltage regulator, providing 120VAC, 60 Hz, 1500 Watts.
  • J
    Jessica SmithSep 5, 2025
    What causes AIRLESSCO Paint Sprayer to leak paint down outside of pump?
    • M
      Mary SchmidtSep 5, 2025
      If paint leaks down the outside of the pump of your AIRLESSCO Paint Sprayer, it is likely that the pump packings are worn and need replacement.
  • K
    Karen WilsonSep 8, 2025
    Why does AIRLESSCO SP200 Paint Sprayer spray paint that runs down the wall?
    • F
      fnguyenSep 8, 2025
      If the paint sprayed by your AIRLESSCO Paint Sprayer runs down the wall or sags, it means the coat is going on too thick. To fix this, move the gun faster. Additionally, consider using a tip with a smaller hole size, a wider fan, and ensure the gun is far enough from the surface.
  • B
    Beth SchultzSep 12, 2025
    Why AIRLESSCO SP200 Paint Sprayer doesn't provide adequate coverage?
    • W
      woodloriSep 12, 2025
      If the coverage from your AIRLESSCO Paint Sprayer is inadequate, the coat is likely going on too thin. Try moving the gun slower. Also, consider using a tip with a larger hole size, a narrower fan, and ensure the gun is close enough to the surface.

Summary

Important Safety Instructions

Warnings

Grounding and Electrical Safety

Details grounding requirements and electric shock hazards.

Fire and Explosion Hazards

Covers fire, explosion, and toxic material risks.

Personal Injury and Chemical Hazards

Addresses skin injection, equipment misuse, and material compatibility dangers.

Toxic Exposure and Protective Equipment

Specifies PPE and handling of toxic fumes and moving parts.

Installation

Grounding and Electric Requirements

Details electrical grounding and connection requirements for the sprayer.

Operation

Pressure Relief Procedure

Setup

Initial Setup Procedures

Priming, flushing, and installing components before first use.

Spraying Adjustments and Techniques

Getting Started With Basic Techniques

Shutdown and Cleaning

Pail Flushing

Step-by-step guide for flushing the sprayer using a pail.

Power Flush

Maintenance and Service

Troubleshooting

Motor and Power Issues

Priming and Pressure Problems

Spray Pattern and Flow Issues

Gun and Component Failures

Overheating and Voltage Issues

AIRLESSCO SP200 Specifications
