62 AS-D+—AS-P Series Instruction Manual
AirSep Corporation
AS-N
Product Flow 1,500 – 1,800 SCFH*
39.43 – 47.32 Nm
3
/hr*
707 – 849 LPM*
Product Pressure 45 – 65 psig*
310 – 448 kPa*
3.0 – 4.4 barg*
Product Concentration Up to 95%
Product Dew Point -100°F (-73°C)
Dimensions (W x D x H)
(Nominal)
84 x 48 x 110 in (213 x 122 x 279 cm)
Weight 4,950 lb (2,245 kg)
Physical Connections**
Compressed Air Inlet
Product Gas Outlet
1½” FNPT
¾” FNPT
Ambient Operating Conditions Locate the oxygen generator in a well-ventilated area that is
protected from weather elements and remains between 40°F
(4°C) and 104°F (40°C)
Feed Air Requirements
Pressure (minimum) 90 psig
621 kPa
6.2 barg
Temperature (maximum) 122°F (50°C)
Feed Air Regulator Setting*** 70 – 75 psig
483 – 517 kPa
4.8 – 5.1 barg
Control Power Requirements
(Single Phase)
120 V ~ ±10%, 50/60 Hz, 3.0 A
220 V ~±10%, 50/60 Hz, 1.0 A
Pressure Switch Setting***
(minimum) 65 – 70 psig
448 – 483 kPa
4.4 – 4.8 barg
(maximum) 72 – 75 psig
496 – 517 kPa
4.9 – 5.1 barg
Other Specications
Pollution Degree
Installation Category
Altitude
2
II
2000 m
*SCF (Standard cubic foot) gas measured at 1 atmosphere and 70°F / Nm
3
(Normal cubic meter) gas measured
at 1 atmosphere and 0°C / LPM (Liters per minute) gas measured at 1 atmosphere and 21°C.
**Check the label on the control panel for appropriate power supply.
***Data may vary as per the customer’s requirements.
Table A.7: AS-N Specifications
