User Mode*
Airow Control*
Local Ventilation
Comfort. Default and standard user mode. The desired set point temperature
can be selected using the predened temperature ranges.
Eco. The range of available set point temperatures changes for more ecient
operation.
Night time. The system automatically changes the set point temperature 1º
F/ 0.5º C every 30 minutes in up to 4 increments (4º F/ 2º C in 2 hours). When
cooling, the system increases the set point temperature; when heating, the
system decreases the set point temperature.
Unoccupied. To be used while you are away for short periods of time. A more
ecient set point temperature will be set. If the thermostat is activated, the
zone will start running in comfort mode.
Vacation. This mode feature helps you save energy while you are away for
extended periods of time.
Stop. The air-conditioning system will remain switched o regardless of the
demand status of any zone, and all the motorized dampers will stay opened.
Select the control algorithm that best ts your installation. These are the
available options:
This option allows activation or deactivation of the ventilation in
the selected zone when the system is not actively cooling or heating any of
the zones.
*Only available to the Main thermostat.
*Only available to the Main thermostat.
Important
In Heat Pump installations,
it is recommended not to
activate the global and local
ventilation in a DZK zoning
box connected to the master
indoor unit. It may cause the
Stop user mode to turn o
the rest of the DZK zoning
box.
Silence. The fan speed is lower than in standard mode to reduce the noise.
Standard. Default setting. The system automatically regulates the fan speed
based on the number of zones calling for cooling or heating.
Power. The fan speed is higher than in standard mode to increase the ow.
