23
USING YOUR WIRELESS LITE THERMOSTAT
On/O. Press on the On/O button to turn on or o the zone. This button
also displays the operation mode. It follows a color code system:
Temperature Control. Using the buttons, you can rise or lower the
base set point temperature in increments of ± 1ºF/0.5ºC (by default) or
± 2ºF/1ºC up to a limit of ± 6ºF/3ºC. This base set point temperature can
be congured only through any Wired Thermostat.
The LEDs indicate the steps above or below the base temperature.
Once the three-step limit has been reached, the temperature control
icons will ash.
Purple: Stop User mode.
Red: Heating mode/Emergency heat.
Blue: Cooling and Dry mode.
Green: The set-point temperature has been reached.
If the button is solid lit, the thermostat is ON.
If the button is ashing, the thermostat is OFF.
The botton remains lit for 10 seconds to show the status, then turns o.
Adjusting the temperature
