Airzone DZK - DZK Thermostat Interfaces; Wired Thermostat Interface; Wireless Thermostat Interface; Wireless Lite Thermostat Interface

User’s Manual
Rev. 1.00 Date 03-2017
7
DZK thermostats control the air conditioning and boost the energy eciency of your AC unit.
Both the main and zone thermostats can be easily congured. From your main thermostat you can select
the available operation modes or dene the energy eciency (prole).
DZK INTERFACES
WIRED THERMOSTAT. Interface with a 3.5'' color touch
screen for controlling the zone.
• Control of set point temperature. Displayed in 1ºF/0.5ºC
increments.
• Congurable set point range for Cooling and Heating.
• Room temperature and relative humidity reading.
• Operation mode, User mode and Airow control (only
available for the Main Wired Thermostat).
• Timer function.
• Zone navigation.
• Time schedules.
• Congurable as Main or Zone thermostat.
WIRELESS THERMOSTAT. Low-energy E-ink thermostat for
controlling the zone through capacitive buttons.
• Control of set point temperature. Displayed in 1ºF/0.5ºC
increments.
• Congurable set point range for Cooling and Heating.
• Room temperature and relative humidity reading.
• Timer function.
• Zone navigation (only if no Wired Thermostat available).
WIRELESS LITE THERMOSTAT. Interface for controlling
the air conditioning through capacitive buttons.
• On/O button.
• Allows adjustment of the base set point temperature in
increments of ± 1ºF/0.5ºC (by default) or ± 2ºF/1ºC up to a
limit of ± 6ºF/3ºC. This base set point temperature can be
congured only through any Wired Thermostat.
• Room temperature and relative humidity sensing.
1
72
ZONE 01
70º- 52%
º
ZONE 01
º
72
70º - 52%
